Electric Duct Heater

VIC Electric Duct Heaters are designed for use in all forced air commercial and industrial HVAC systems. Their applications vary from a partial or auxiliary nature to being the major or principal heat source in a building. Electric Duct Heaters are custom designed to the most stringent UL-1996 standard to assure total safety.

SALIENT FEATURES OF EDH
  • Face Size Range: 6” x 6” up to 144” x 96”
  • Maximum Heating Capacity: 1000 KW (single section)
  • Large Duct Sizes and Multiple heaters can be made and field installed together to accommodate large duct sizes or Heating Capacities (KW’s).
  • Heating Density: 22.5 KW per square foot of duct area
  • Maximum Applicable Voltage: 600 V / 3 Phase
  • Primary Thermal Protection: Auto Reset disc cut out
  • Secondary Thermal Protection: Manual Reset disc cut out (for all heaters of 30 KW and less and not in excess of 300 volts )
  • All Heaters can be equipped with a variety of control options to accommodate any control system from basic electric, electronic or pneumatic to the most sophisticated DDC control (Direct Digital Control).
  • Standard Control Panel: NEMA 1
  • Electric Duct Heaters are built with components that have been selected according to a very demanding set of criteria to guarantee a reliable and durable operation.
PRODUCT CERTIFICATION:

The following Electric Duct Heaters are UL listed as per UL– 1996 standard:

  • Face Size Range: 6” x 6” up to 144” x 96”
  • Maximum Heating Capacity: 1000 KW (single section)

The following models are covered under the UL file:
FCA (a), FCC (a), FCF (a), FCK (a), FCM (a), FCP (a), FCS (a), FCT (a), FTA (a), FTC (a), FTF (a), FTK (a), FTM (a), FTP (a), FTS (a), FTT (a), SCA (a), SCC (a), SCF (a), SCK (a), SCM (a), SCP (a), SCS (a), SCT (a), STA (a), STC (a), STF (a), STK (a), STM (a), STP (a), STS (a), STT (a).

Primary Models

SC Slip-in Open Coil (Fig. 1)
ST Slip-in Tubular
FC Flanged Open Coil
FT Flanged Tubular (Fig.2)
RFC Round collar open coil (Fig. 3)
RFT Round collar with Tubular elements

Single Section Heater Duct Size Limits

Maximum Size of Heater

Inches

Max. duct width

144

Max. duct height

72

Max. duct depth

60

General Characteristics, Model Classifications, Standard Features, Optional Features, Selection Procedure, and etc. Please refer to our Catalogue

Product Technical Catalogue
